The CR PAL M model offers palletizing solutions to our users in different product types. As with all our product models, you can choose the product and pallet entry/exit directions according to your needs.
M Series, which responds to different product and pallet sizes, can perform the palletizing process of up to 1400 products per hour with the CReatePAL® pattern software, which the user can teach within 3 minutes.
Servo motor controlled turning unit can make any direction you want by simply lifting it from the bottom surface without applying any impact or vacuum pressure to the surfaces of your products.
| Maximum Pallet Height and Weight: | 2400mm / 1400 Kg |
| Capacity and Maximum Product Weight | 1400 products/hour 50 Kg |
| Control |
- CReatePAL® Pattern Software Based Touch Screen - PLC Controlled Automation |
| Features |
– Automatic Empty Pallet Feeding – Slip Sheet Loading Robot – Barcode Reading Feature - Servo Motor Controlled Rotate Unit and Pusher Group - Working with Different Pallet Models - -Sack, Case, Stretched Product, Bucket, Crate Palletizing |
| Safety |
– Operator Protection with Light Barrier Control - Pallet Lift Fall Detection System |
| Dimensions / Power | – 6800 mm x 2000mm x H2400mm / 380 V 50 Hz, 10 KW |
software is a special software solution developed for the
machine family. It offers our users an easy-to-use, flexible and intuitive solution for pallet
patterns. In a total of 3 minutes, you can generate your product and create the patterns on the
pallet.
